Carat Septic Tank

£990.00£1,380.00

Floating and removable material is extracted from domestic wastewater in mechanical septic tanks. This is pure mechanical cleaning, for which you need 500 l of capacity per inhabitant.

Enquire Now
SKU: CARAT-SEPTNK Category: Tag:

Floating and removable material is extracted from domestic wastewater in mechanical septic tanks. This is pure mechanical cleaning, for which you need 500 l of capacity per inhabitant. If you assume a volume of 150 l, the wastewater passes through the system in 3 days. These septic tanks must have a total volume of at least 2,000 l. A 2,000 l system is sufficient for 4 inhabitants, another 500 l, must be incorporated for each additional inhabitant.

  • Low weight: can also be installed in difficult local conditions without a crane
  • Reasonable purchase and installation costs. Compare!
  • Low maintenance: maintenance or cleaning work can be performed through the shafts
  • Tanks can be used as rainwater harvesting systems after thorough cleaning

Technical Data

System
Max. earth covering (without groundwater vehicle loading)1200mm (47.2″)
Max. vehicle weightSuitable for vehicle loading (3.5 t) Higher loads on request
Earth covering required for vehicle loading800 – 1200mm (31.5 – 47.2″)
Groundwater stabilityup to middle of tank
Earth covering required for groundwater stability800 – 1100mm (31.5 – 39.4″)
ConnectionDN 100 / DN 150 / DN 200 on top

Tank Info

Dimensions
Volume [l]2,7003,7504,8006,500
Width b [mm]1565175519852190
Length l [mm]2080228022802390
Height h [mm]1400159021102390
Height htot [mm]2010220027203000
Height of tank dome ht [mm]610610610610
Inner Ø of tank dome [mm]650 – 800650 – 800650 – 800650 – 800
Weight [kg]120150185220
